Goford 150V P-MOSFETs: Ultra-Low RDS(on) for High-Power Apps
2025-04-02
In today's high-performance electronics landscape, power density and thermal efficiency are critical. Goford Semiconductor introduces the GT880P15 series, including GT880P15D5, GT880P15K, and GT880P15T, 150V P-Channel MOSFETs engineered for ultra-low RDS(on), high-current operation, and robust packaging options, delivering unmatched performance in space-constrained applications.
Product Highlights:
150V Voltage Rating: Robust performance for industrial and automotive power systems requiring high-voltage operation.
Ultra-Low RDS(on): As low as 82mΩ at VGS=10V, minimizing conduction losses and boosting efficiency.
High Current Capacity: Supports -30A continuous current (TC=25∘CTC=25∘C) and -120A pulsed current, ideal for heavy-load applications.
Multiple Packaging Options: Multiple packaging methods for diverse scenarios.
Avalanche Resilience: Single-pulse avalanche energy (EAS) up to 156mJ, ensuring reliability in surge-prone environments.
Product Parametrics:
| Part Number | Package | ESD | Vds(V) | Id(A) | Rds(on)mΩ(typ) @Vgs=10V | Rds(on)mΩ(max) @Vgs=10V | Qg(nC) | Ciss(pF) |
| GT880P15D5 | DFN5X6-8L | NO | -150 | -30 | 82 | 90 | 46 | 3350 |
| GT880P15K | TO-252 | NO | -150 | -30 | 79 | 100 | 46 | 3350 |
| GT880P15T | TO-220 | NO | -150 | -30 | 79 | 100 | 46 | 3350 |
Applications:
Motor Drives Power Tools Industrial Power Systems
